What exactly is stereo lithography, or SLA? Stereo lithography (SLA) is one of several methods used to create 3D printed objects. It works by forming a part or object by curing layers of a liquid plastic that is sensitive to light. A CAD file that has been converted to an STL file, which digitally divides a 3D model of an object into layers, serves as the blueprint for the precise layering.
Each layer of photopolymer is exposed to a UV (ultraviolet) laser that immediately cures, or hardens it. Until a complete three-dimensional object is formed, subsequent layers are cured and bonded to the previous layer. After that, it is cleaned, and the photopolymer can be further cured by baking it in a UV kiln. SLA produces prototypes and small, precise objects faster than typical machining.
This makes stereo lithography printing ideal for detailed parts including jewelry, dental models, medical models and implants, and other things that would be expensive to machine otherwise. SLA Printing Advantages and Disadvantages SLA printers are popular for their ability to produce intricate objects and parts with a high degree of accuracy. Because they are relatively inexpensive, this method uses printers frequently in offices. SLA printing produces strong odors due to curing photopolymers in the printing process, and the risk of warping in larger items. It’s generally best for smaller parts, and most parts are not particularly strong.
History of SLA Printing In 1981, a functional rapid-prototyping system using photopolymers was invented by Hideo Kodama, which made a solid, printed model from many layers, each of which corresponded to a sectional slice in the model. Three years later, in 1984, Charles Hull invented the solid imaging process known as stereo lithography —one of the earliest and most widely used forms of 3D printing — along with the STL file format that is necessary for translating CAD files for 3D printers. What is the difference between FDM printing vs SLA printing? FDM (fused deposition modeling) and SLA (stereo lithography) are both methods of 3D printing.
Layer by layer, both objects are printed. SLA uses a curable photopolymer that is hardened by applying a UV light. SLA printers typically build a three-dimensional object from top to bottom. The build platform lifts the object upwards out of the resin bath. FDM printers use thermoplastic, which is heated to its melting point and then extruded in layers to create a three-dimensional object. How thick are the layers created by SLA? The photopolymer is applied in thin layers, usually between.
What is a photopolymer? Also known as a resin, a photopolymer is an acrylic-based, liquid plastic material that instantly turns into a solid part when exposed to UV light. Why should an ultraviolet laser be used? Lasers are fast and precise, so they can produce highly accurate models and prototypes. The curing and hardening of photopolymers caused by an ultraviolet (UV) laser accelerates production. What kind of post processing is needed with SLA printing? Parts need to be rinsed in isopropyl alcohol to remove any uncured resin. Parts may need additional curing to increase strength from their surface, and sanding is often required to attain a desired surface. What is an STL file? CAD files show a rendering of a 3D object; STL (Standard Tessellation Language) acts as a translator that digitally slices that image into layers, creating a file that can then be used to direct 3D printing machines in creating the object.
Mastering resin 3D printing settings is crucial for beginners aiming to achieve high-quality prints. Since there is so much to learn before your first successful print, starting can feel overwhelming. Common questions like “Where do I begin?”, “What are the best resin 3D printing settings?”, and “What model should I print first?” often arise. But don’t worry—you’re not alone in this journey! This guide will walk you through the essential resin 3D printing settings that every beginner should know. By the end, you’ll feel confident about diving into the fascinating world of resin 3D printing. Still deciding on your first printer? For more information on the best resin 3D printer for beginners, check out our comprehensive guide. It will help you pick the right machine to match your goals and budget. Unfortunately, many online resources about resin 3D printing are scattered and incomplete.
When it comes to resin printing, there are a lot of parameters and environmental factors to consider, so concentrating on just a few settings rarely suffices to resolve common issues. If you don’t know how changes will affect things, it can feel like a pointless guessing game. This guide simplifies resin 3D printing by explaining essential settings using terms from popular slicers like Chatterbox, Lychee, Voxeldance Tango, PrusaSlicer, and Z-Suite.
You’ll gain a clearer understanding of what you can control, making it easier to troubleshoot and improve your prints. Don’t miss our Business Resin Printing Setup Guide & Checklist if you’re setting up a workspace for resin printing, especially for business use. It provides expert tips for creating a safe and efficient environment. By mastering these resin 3D printing settings, even beginners can achieve professional-level print quality. Whether you’re just starting or looking to refine your skills, this guide is your ultimate resource for superior results. The calibration part is your best friend Printing a calibration part is essential whenever a new 3D printer is set up, a new resin is used, or a failed print with no obvious cause occurs. You can effectively troubleshoot issues and fine-tune your settings with calibration parts. Fortunately, a large number of free calibration parts can be downloaded.
